Mount John University Observatory (MJUO)




Site
Latitude and longitude: -43:59:08, 170:27:54E (-43.98557, 170.46503)
Elevation: 3376ft (1029m)
Site manager: Alan Gilmore
Internet access: high speed fiber
Weather statistics: 20% photometric, 40% useable, 40% cloudy
Typical good seasons:


Optical Craftsman 0.61m Telescope (OC61)


Telescope

Type: Cassegrain
Aperture: 24in (61cm)
Focal length: 9020mm
F-ratio: 14.8
Focuser: electric secondary plus FLI

Mount
Type: fork
Pointing accuracy: 1arcmin
Maximum unguided tracking: >5min
Restrictions, if any: airmass less than 2
Computer: Linux + Windows
Software: TheSky, MaxIm DL, ACP, ACP Scheduler
Telecope Advocate: A. Henden

Imaging
Typical seeing: 1.5arcsec
Best seeing: 1arcsec
Vignetting:
Scattered light:
Image defects:

Camera
Camera: FLI PL09000
Filter wheel: FLI 5 slot
Filters: BVgri
Exposure ratios/filter:3.5:1.6:1.8:1.0:1.1
Pixel count: 1528x1528 (after 2x2 bin)
Pixel scale: 0.549arcsec/pix
Field of view: 14x14arcmin
Gain:
Readnoise:
Linearity (graph)
Full well: 65K ADU
Cosmetic defects:
Dark current:
Read time: 5sec
Shortest exposure: 0.2sec (iris shutter)
Compressed image size: 2.5MB
QE response (graph)

Images of typical darks, typical flats

Typical Use of System

Deep imaging

Miscellaneous Notes
